Incorrect elements will be copied on the error layer. There is an option to perform an integrated merge before performing the check. A further option will also check the existence of slots in a single shape.Īll elements on a chosen layer are checked on minimum size. That option will allow detecting notches created by touching shapes. Optional a merge operation is performed before. Also, the location of the defect will be marked.Ĭhecks for notches smaller than an entered value. Optional a merge before the check can be performed to avoid violation in joining shapes. Shapes on a chosen layer with a distance less than an entered value are marked as a violation.
If the distance of the point to the edge exceeds or falls below an entered value a violation is triggered. This point is also called Pole of Inaccessibility. The check will calculate the point inside the shapes located mostly remote from any edge. Optional a merge operation before the check is possible to get the correct dimension of touching shapes. The dimension is measured in the orientation along the x/y axis. The area used twice or more time in a check square will be counted twice.Ĭheck for minimum/maximum/exact dimensions.
#LAYOUTEDITOR FIND MINIMUM VALUE FREE#
It will be check for a minimum and maximum relation of the area used by the layer and free area. Optional a merge operation before the check can be performed to get the correct area of touching shapes.Ĭhecks the density of a single layer in the design. It can be checked for a minimum area and for a maximum area of that shape. Optional a merge operation before the check is possible. It can be checked on acute angles, 45°angle, and 90°angles.
